LXD63L600

LXD 600 Amp, 600V, Circuit Breaker, Siemens LXD63L600, LXD 600A | aka: ITE LXD63L600, ITE Siemens LXD63L600, UPC: 783643214316

Description:

• Siemens LXD63L600, LXD 600 Amp, 600V, Circuit Breaker, LXD 600A | aka: ITE LXD63L600, ITE Siemens LXD63L600, UPC: 783643214316
• Bolt On Mounting
• Frame Type: LXD
• Dimensions: 7.5 Inch Wide x 11 Inch High x 4 Inch Deep
• Weight: 20lbs.
• Wire Size: Lug Kit TA2J6500 (3/0 AWG to 500 Kcmil)
• LXD, 600A, 600V AC, 3 Pole
• Interrupting Rating at 240 Volts AC: 65,000
• Interrupting Rating at 480 Volts AC: 50,000
• Interrupting Rating at 600 Volts AC: 25,000
• Magnetic Trip
